20 Tons Ferry Rail Transfer Trolley

Brand Name : Remarkable

Model Number : RGV

Certification : CE, ISO

Place of Origin : Henan, China

MOQ : 1

Price : Negotiable

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 600sets

Delivery Time : 30-45 work days

Packaging Details : 1. Main body of the machine is packed with high-quality waterproof plastic cloth. 2. Electrical parts are specially protected, and the spare parts are packed in standard export fumigation free wooden boxes.

Power supply : Battery/cable powered/Low voltage track

Load : 1-500 tons

Ground type : rail

Operation method : Wireless remote control & Hand operate pendant

Traveling speed（m/min） : 0-35 (Stepless speed regulation)

Other function : Automatic weighing,roller,lifting table etc.

Product name : Self Propelled Rail Transfer Cart

table size : customized

Wheels type : Cast Wheel; Forged Wheel

high light : towed rail trolley,20 tons rail transfer cart,rail trolley

Contact Now

20 Tons Ferry Rail Transfer Trolley

4 set 20t capacity busbar Powered Rail Transfer Trolley was delivered to Shenzhen Factory and Chongqing plant, which is our long term cooperated client. Compared with the common type of transfer trolley, The transfer trolley is divided into upper and lower bodies, which can slide on the track at the same time. The lower body, also known as the mother car, runs on the ground laying track, and the upper body, also known as the sub car, can run on the track laid by the lower body or be transported to the designated position by the mother car, and then leave the mother car to run on the ground track.

This kind of rail transit vehicle is usually called a ferry rail transfer trolley, The ferry transfer cart can be used on various occasions, such as cargo handling, and rail transit. Cargo transport and rail transit ferry can also be used simultaneously. Usually, the ferry transfer cart is divided into two sections: upper part and lower car bodies, one for transshipment and one for the ferry. Meanwhile, we have a professional and excellent team who can make it with three layers of car body according to your needs to meet the working site requirements. It’s widely used in metallurgy, machinery manufacturing, heavy industry manufacturing, mold manufacturing, steel plate distribution, building materials handling, etc.

20 Tons Ferry Rail Transfer Trolley

Technical parameters for rail power transfer carts
Model KPG-6t KPG-10t KPG-16t KPG-25t KPG-40t KPG-63t KPG-100t KPG-160t KPG-200t
Rated load (t) 6 10 16 25 40 63 100 160 200
Countertop size(mm) Length 3600 3600 4000 4500 5000 5600 6300 8000 8200
Width 2000 2000 2200 2200 2500 2500 2800 2800 3000
Height 550 550 600 650 700 850 900 1100 1250
Speed(m/min) 30 30 30 30 25 25 20 20 18
Wheelbase A(mm) 2000 2200 2200 2500 2800 3200 3600 5000 5000
Track medial distance C(mm) 1435 1435 1435 1435 1435 1435 1650 2000 2000
Wheel diameter(mm) 400 400 400 500 500 600 700 700 700
Bottom clearance(mm) 50 50 50 60 60 60 60 70 70
Minimum turning radius 30 35 50 55 60 80 100 100
Power mode Battery/low-voltage rail/ Cable Drum/cable reels/Dragged Cable / busbar powered
Recommended track model 24kg/m 38kg/m 43kg/m QU80 QU100
Number of wheels 4 8
Maximum wheel Pressure (t) 1.91 3.21 4.87 7.5 11.5 16.9 27.6 22.8 28.5
Reference weight (t) 3.4 3.72 4.2 6 8.5 11.4 15.2 25.5 31.5
Note 1) Other gauges, table sizes, and load tonnages can be customized according to user requirements;
2) Imported and domestic industrial wireless remote-control devices are optional;
3) Optional imported wireless two-speed control;
4) Optional matching automatic parking, and alarming when encountering person 2 meters away.

20 Tons Ferry Rail Transfer Trolley

Remarkable Transfer Trolleys are divided into a track Ferry Transfer Trolley and a trackless Ferry Transfer Trolley. The power supply can be a battery or cable. We have added a PLC programming control system, and people automatically stop and other functions to ensure safety during operation. The touch screen, joystick operation, and other designs make the operation more user-friendly.

Remarkable can customize different function transfer trolley, welcome to inquiry for more information.

20 Tons Ferry Rail Transfer Trolley

20 Tons Ferry Rail Transfer Trolley20 Tons Ferry Rail Transfer Trolley20 Tons Ferry Rail Transfer Trolley20 Tons Ferry Rail Transfer Trolley20 Tons Ferry Rail Transfer Trolley20 Tons Ferry Rail Transfer Trolley
