5 Tons Steerable Transfer Carts With Hydraulic Lifting System

Name: 5 Tons Steerable Transfer Carts With Hydraulic Lifting System
Brand: Remarkable
Price: 1 USD

5 Tons Steerable Transfer Carts With Hydraulic Lifting System Manufactures

Brand Name : Remarkable

Model Number : RWP-5T

Certification : CE, ISO9001

Place of Origin : China

MOQ : 1 set

Price : Negotiable

Payment Terms : T/T, L/C, D/A, D/P, Western Union, MoneyGram

Supply Ability : 500 sets per year

Delivery Time : 30-45 work days

Packaging Details : 1. Main body of the machine is packed with high-quality waterproof plastic cloth. 2. Electrical parts are specially protected, and the spare parts are packed in standard export fumigation free wooden boxes.

Power supply : Maintenance free battery

Load : 5 tons

Table size : Customized

Operation method : Wireless remote control & Hand operate pendant

Traveling speed（m/min） : 0-20 (Stepless speed regulation)

Brake mode : Electromagnetic brake

Battery charger function : Automatic charging

Move Way : Forward, backward, turning while driving with no stop

Contact Now

^{5 Tons Steerable Transfer Carts With Hydraulic Lifting System}

^{5 Tons Steerable Transfer Carts With Hydraulic Lifting System Is One Kind Of Transfer Equipment For Material Handling In The Workshop.The Trolley Is An Ideal Device And The Customer Needs A Sophisticated Handling Solution In Very Narrow Spaces.This Kind Of Large Table Size And Heavy Load Transfer Trolley Adopts The Hydraulic Steering Device To Make The Cart Turning Freely And Meets Client's Small Space At Using Site.}

Main Features:

1. Standard Equipment

2. Improves Security And Efficicency

3. Convenient Maintenance And Long Service Life

4. Safety And Flexibility

5. The Flat Car Can Be Equipped With Hydraulic Lift

5 Tons Steerable Transfer Carts With Hydraulic Lifting System

^{There Are Different Classifications Of Transfer Car According To The Type Of Wheels:}

^{– Rail-Mounted Self-Propelled Trailer. With Straight Path Rails, With Curved Path Or Even With Crossings With Other Rails.}

^{– On Floor With Polyurethane Wheels}

^{– Conventional Movement (Rear-Wheel Drive Type) A Steering Axle And Another Drive Axle.}

^{– Dual Axis Movement, Two Axes Both Directives And Motors Simultaneously.}

^{– Omnidirectional Movement (Multi-Wheeler Type), Several Sets Of Wheels That Include Independent Traction And Rotation Allowing Displacements In All Directions.}

5 Tons Steerable Transfer Carts With Hydraulic Lifting System

Technical parameters for electric transfer carts
1	rated load(t)	5	10	15	20	30	40	50	150
2	impacted rated load(t)	7.5	15	22.5	30	45	60	75	225
3	structure of frame	steel plates welded, beam structure
4	max. wheel load(t)	2.8	4.3	4.8	5.6	7.7	10	12	27
5	ground requirement	cement floor					steel plate ground
5	ground requirement	cement floor					steel plate ground
6	table size(mm)	3000×2000	3600×2000	4000×2200	4500×2200	5000×2200	5500×2300	6000× 2300	10000× 3000
7	height of the whole cart(mm)	450	530	600	600	650	700	700	1200
8	ground clearance(mm)	50							75
9	wheels base(mm)	1500		1700			1800		2000
10	axles distance(mm)	2500	3100	3400	3900	4300	4800	5200	10000
11	turning radius(mm)	2501	3101	3401	3901	4301	4801	5201	10001
12	turning type	turning while driving with no stop
13	control method for turning	control button
14	turning structure	mechanical
15	motor power(Kw)	3.5	5	6	7	10	12	15	15
16	wheel diameter(mm)	Ф300 x 4	Ф350 x 4		Ф400 x 4	Ф400 x 6	Ф500 x 6		Ф600 x 8
21	battery model	D-250 x 24	D-33 x 24	D-400 x 24	D-440 x 24	D-250 x 36	D-330 x 36	D-440 x 36	D-600 x 36
22	battery maintenance	free of maintenance
23	charger's installation	installed on cart				split-type
24	charger function	automatic charging
25	radar control	3-0.3m, automatic stop for obstacles
26	warning equipment	sound and light
27	other functions	turning light, night light and power display
