Battery Transfer Cart Industry Handling Trolley
Generally speaking, the driving behavior on the track is limited. In order to solve these problems, Remarkable Handling Equipment has developed non-standard vehicles such as turntables, turning vehicles, and shuttle vehicles to assist in the use. We design and manufacture trackless transfer carts, get rid of the rail constraints, walk directly on the ground, and use battery power supply, energy-saving and safety, is a new energy carrier, is a new star of material handling equipment.
The RWP trackless transfer trolley is a special traveling mechanism that can realize flexible turning under a small turning radius. It is a unique product of the Remarkable family.
The trackless turning vehicles are powered by batteries. In order to realize turning, the turning vehicle is equipped with a special steering mechanism, which can be used for turning paths such as C-shape, S-shape, or straight-line + curve. The flexibility of the trackless transport platform is less than that of the track turning vehicle, but the turning radius requirements must be based on the transfer cart Customized table size. The trackless transport car is driven by two motors, uses a mechanical turning, and runs flexibly.
The trackless battery transfer cart does not have tracks, which not only does not require users to lay tracks, but also saves track purchase costs and maintenance costs. Without the track, it can travel on any ground and can realize circular 360-degree operation, which is suitable for the use of lines.
Contact Us For A Free Consultation Based On Your Requirements. Remarkable Sells Its Battery Transfer Cart Industry Handling Trolley Worldwide!
Customized Automatic Trackless Trolley technical parameter:
| No. | Model | RWP trackless transfer cart |
| 1 | Load(t) | 10 |
| 2 | Table size(mm) | 6000×2500 |
| 3 | Height(mm) | 600 |
| 4 | Ground clearance(mm) | 100 |
| 5 | Ground-type | Cement floor, Self-leveling |
| 6 | Climbing slope | No more than 2 degrees |
| 7 | Move Way | Forward, backward and rotate 360 degrees, turning while driving with no stop |
| 8 | Operation method | Wireless remote control & Hand operate pendant |
| 9 | Traveling speed(m/min) | No-load 30, load 10 |
| 10 | Power supply | battery |
| 11 | Brake mode | Electromagnetic brake |
| 12 | Battery model | 48V120Ah |
| 13 | Charger install type | Split-type |
| 14 | Battery charger function | Automatic charging |
| 15 | Safety device | Audible and visual alarm lamp and emergency stop button, Ultrasonic obstacle avoidance |
| 16 | Other functions | Warning light, power display, over-voltage, under-voltage, over-current protection |
We have examples of exporting industrial and material transfer vehicles in many countries of the world:
Remarkable Industrial rail transfer cars have the battery power supply, low-voltage rail power supply, cable reel power supply, and trolley line power supply; the track laying requirements of rail flat cars need to be made according to the power supply and factory conditions, such as low voltage Rail power supply requires insulation treatment; high-temperature resistance treatment is required under high-temperature conditions. In addition, the customization of industrial rail cars needs to be customized according to the specific needs of users, and the size of the design needs to be calculated by the technicians for the load.
In comparison, trackless transfer vehicle is more popular with customers, and it is also the mainstream of the transportation industry in the future. But it depends on the customer's factory and use conditions to decide whether to choose trackless or rail transfer carts. No matter what kind of car, Remarkable can design and manufacture according to the needs of customers.
